 Product description

The series for inverter and solar charge discharge controller and battery charger integrated design referred to as inverse control of various filling machine; this is a with high performance, high reliability, load ability, perfect protection, intelligent charging control management function of reverse charging power supply, DC voltage 12V inverter occasions for; can provide reliable pure sine wave power supply for business, household, workstations, home appliances, air conditioning equipment, single-phase power equipment, industrial equipment, power is not more than the product of the rated power. In short it is a powerful, a wide range of intelligent high frequency power control.



Product characteristics

1, Pure sine wave output;

2, LED display, you can visually display all the running parameters of the machine;

3, high conversion efficiency, conversion efficiency of 90%, low loss;

4, carrying capacity and anti load capacity;

5, perfect protection function: low pressure, high pressure, high temperature, short circuit, overload, reverse connection protection, etc.;



technical parameter

Inverter Parameters Model JYSYP-3000
Rated power 3000W
Peak power 6000W
Input voltage DC12V DC24V
Output voltage 110VAC or 220VAC±5%
Unload current less than 1.3A 0.8A
Output frequency 50Hz±0.2Hz or 60Hz±0.2Hz
Output waveform Pure Sine Wave
Waveform distortion THD<3%(Linear load)
USB port 5V 1A
Max.efficiency 90%
Input current 10A
Input voltage range 10-15.5V 20-31V
Low voltage alarm 10.5±0.5V 21±0.5V
Low voltage protection 10±0.5V 20±0.5V
Over voltage protection 15.5±0.5V 31±0.5V
Low voltage recover 12.3±0.5V 24±0.5V
Over voltage recover 14.8V±0.5V 29.5V±0.5V
Low voltage Alarm at first, voltage continously reduce. LED Red light on & shut sown.
Over voltage LED Red light on, shut down
Over load LED Red light on, shut down
Over temperature Alarm at first, tempurature continously rise.LED Red light on & shut sown
Short circuit LED Red light on
Input reverse polarity Fuse burn-out
Solar Charger Parameters Battery 12V
Charging voltage 14.5V±0.3V
PV Input Current 10-40A
PV Input Voltage 25V(Max)
Low Voltage Disconnection 9.5V±0.5V
Low Voltage Reconnection 12.6V±0.3V
Other Parameters Working temperature -10°- +50°
Storage temperature -30°- +70°
Dimension(mm) 300x180x128mm
Packing(mm) 380x240x195mm
Net./gross weight(g) 4100/4730g
QTY/Ctn 4pcs
Meas./Ctn(mm) 505x405x420mm
Gross weight/Ctn(g) 18920g
Warranty 1 years
Configuration Standard
Cooling method Intelligent air cooling

Note: Our products update constantly.The technical parameter is for reference only.Please refer to our real product.
