Feature: ● Constant voltage mode power supply Specification IP67 |
|||||
Model |
LPV-120-12 |
LPV-120-24 | LPV-120-36 | ||
Output |
DC output voltage |
12V |
24V |
36V |
|
Output voltage error |
±1% |
±1% |
±1% |
||
Rated output current |
10A |
5A |
3.3A |
||
Output current range |
0~10A |
0~5A |
0~3.3A |
||
Output power |
120W |
120W |
119W |
||
Wave and noise |
100mVp-p |
150mVp-p |
150mVp-p |
||
Set up, rise, hold up time |
800ms,36ms,20ms/230VAC |
||||
Input |
Input voltage range |
180~264VAC 47~63Hz,255~373VDC |
|||
AC input current |
1.5A/230VAC |
||||
Efficiency |
82% |
84% |
85% |
||
Impulse current |
Cold-start current 40A/230VAC |
||||
Leakage current |
<2.5mA/240VAC |
||||
Protection Feature |
Overload protection |
Rated output power 105%~135% set overload protection |
|||
Protection type:pulsing hiccup shut down abnormal overload condition. auto recovery |
|||||
Overpressure protection |
15~17V |
30~32V |
42~44V |
||
Protection type:pulsing hiccup shut down abnormal condition auto recovery |
|||||
over temperature protection |
Enclosure temperature≥85℃,set over temperature protection |
||||
Protection type:Cutting output, temperature recovery. auto recovery |
|||||
Condition |
Working temperature and humidity |
-10℃~+60℃;20%~90%RH (Reference derating curve) |
|||
Store temperature and humidity |
-20℃~+85℃;10%~95%RH (No Condensation) |
||||
shock resistance |
10~500Hz,2G 10min./1cycle,period for 60 min,each axes |
||||
Safety |
Withstand voltage |
Output and input interval:1.5KVAC Input enclosure:1.5KVAC Output enclosure:0.5KVAC |
|||
Isolation resistance |
Output and input interval,Input and Output enclosure:100M Ohms/500VDC |
||||
Meet standards |
Safety standards |
Meet UL1012 IP67 |
|||
EMC standards |
Meet EN55022,CLASSA |
||||
Others |
Weight |
1.2kg 222*69*43(L*W*H) |
|||
packing |
1.2kg/20pcs/25kg |
||||
Notes: 1. The testing condition for the parameter above is:230VAC input, rated load,25℃. |
